Motor vehicle
| Volkswagen Touran |
 |
| Overview |
| Manufacturer | Volkswagen |
| Production | 2003-present |
| Body and chassis |
| Class | Compact MPV (M) |
| Body style | 5-door MPV |
| Layout | Front-engine, front-wheel-drive |
The Volkswagen Touran is a compact multi-purpose vehicle (MPV) manufactured by German automaker Volkswagen since 2003 and sold in Europe and other select markets. It sits between a gap in Volkswagen's model lineup of the Volkswagen Golf, which it shares its platform with, and the Volkswagen Sharan, its larger counterpart. In some regions, such as Japan, the car is called the Golf Touran. The name 'Touran' is derived from the combination of 'Tour' and 'Sharan'. Despite the similarity of their names, the Touran is not related to the North American market Volkswagen Routan. Along with the Renault Scénic, it is the most popular compact MPV in Europe.
The vehicle is delivered in five or seven seat versions.
First generation (Typ 1T; 2003) [edit]
Motor vehicle
| First generation (1T) |
 |
| Overview |
| Also called | Volkswagen Golf Touran (Japan)[1] [2] |
| Production | 2003–2015 |
| Assembly | - Germany: Wolfsburg
- China: Anting (SAIC-VW)
- Indonesia: Jakarta (National Assemblers)[3]
|
| Body and chassis |
| Platform | Volkswagen Group A5 (PQ35) |
| Related | Volkswagen Golf Mk5
Volkswagen Golf Plus
Volkswagen Caddy Mk3 |
| Powertrain |
| Engine | Petrol and CNG engines
1.2 L I4 TSI (2010–2015)
1.4 L I4 TSI (2007–2015)
1.4 L I4 TSI EcoFuel (2009–2015)
1.6 L I4 (2003–2010)
1.6 L I4 FSI (2003–2006)
1.8 L I4 TSI (2005–2008; China)
2.0 L I4 FSI (2003–2006)
2.0 L I4 EcoFuel (2006–2009)
Diesel engines
1.6 L I4 TDI (2010–2015)
1.9 L I4 TDI (2003–2010)
2.0 L I4 TDI (2003–2015) |
| Transmission | 5 speed manual
7 speed DSG |
| Dimensions |
| Wheelbase | 2,680 mm (105.5 in) |
| Length | 2003–2006: 4,389 mm (172.8 in)[4]
2006–2010: 4,409 mm (173.6 in)[5]
2010–2015: 4,397 mm (173.1 in)[6] |
| Width | 2003–2006: 1,791 mm (70.5 in)[4]
2006–2010: 1,791 mm (70.5 in)[5]
2010–2015: 1,793 mm (70.6 in)[6] |
| Height | 2003–2006: 1,651 mm (65.0 in)[4]
2006–2010: 1,641 mm (64.6 in)[5]
2010–2015: 1,674 mm (65.9 in)[6] |
Pre-facelift Volkswagen Touran
The Touran, launched in 2003, is the first Volkswagen MPV based on a Golf platform. It joined Volkswagen's existing MPV line up that included the Sharan and Caravelle (Volkswagen Bus).[7]
It can be considered an extended version of the Golf Plus, since their front ends are similar in size, while the Touran's rear overhang is 200 mm (7.87 in) longer (and therefore a seven-seater, while the Golf Plus is a five seater).
The Touran introduced electro-mechanical steering, a first in its class and for Volkswagen. It is able to vary the weight of the steering depending on the road speed. Due to the lack of energy consumption in idle it also improves the overall efficiency of the vehicle. The Touran was the first vehicle to use Volkswagen's 2.0 TDI engine.
The engines available at the launch included a 1.6 FSI and two diesel engines, the 1.9 TDI with 74 kW (101 PS; 99 hp) and the 2.0 TDI 103 kW (140 PS; 138 hp). The engines are EURO 4 compliant, except the 1.9 TDi when paired with the DSG (direct shift gearbox). The Touran launched with a six speed manual gearbox as standard, and a DSG for the 1.9 TDI Engines.[ citation needed ]
Safety [edit]
The initial test of the Touran in 2003, resulted in a four star rating for adult protection.[8] Volkswagen made slight changes to the Touran from November 2003, adding "an intelligent reminder for the driver and front passenger to buckle their seat belts." This allowed the Touran to be retested the same year, scoring a single extra point, and so giving the car a five star rating for adult protection:
Facelift (2006) [edit]
The Touran received a facelift for the October 2006 Paris Motor Show.
Park Assist [edit]
The 2007 model year Touran was the first production vehicle in the Volkswagen Group to be released with the new Park Assist technology. Park Assist helps the driver parallel park the vehicle. Firstly, after having activated the feature and whilst travelling up to 30 km/h Park Assist uses sensors to attempt to identify a suitable parking spot (defined as 0.8 metres longer than the length of the vehicle).
The driver then stops ahead of the parking spot, releases the steering wheel, but continues working the gears, accelerator and brake pedal as advised by the display panels, as the Park Assist controls the steering to park the vehicle.
CrossTouran [edit]
At the December 2006 Bologna Motor Show, Volkswagen released the third Cross vehicle designed by Volkswagen Individual GmbH.
The CrossTouran is distinguished from a standard Touran by its 17-inch alloy wheels, redesigned plastic guards which ape a crossover vehicle, and a 15 mm (0.59 in) higher suspension/chassis setup that is optional for standard Tourans in Europe.
All CrossTouran engines are EU4 compliant.
Petrol engines
- 1.6 with 75 kW / 102 hp
- 1.4 TSI with 103 kW / 140 hp
- 2.0 TSI with 125 kW / 170 hp
Diesel engines
- 1.9 TDI with 77 kW / 105 hp
- 2.0 TDI with 103 kW / 140 hp
- 2.0 TDI with 125 kW / 170 hp
Second facelift (2010) [edit]
In August 2010, the Touran was updated to the newer Golf VI platform (PQ35). This included as new features compared to the previous facelift the option for DCC (Volkswagen's adaptive suspension system), Light-Assist for Xenon Headlights, an improved Park-Assist System that can also handle perpendicular park positions and updated infotainment systems. The aerodynamics of the car were also improved, the Cw improved from 0,31 to 0,32 to 0,29.
In late 2010, SAIC-VW released the new Touran in China.[10] Though its front was updated to the German style, the tail keeps the design of the phase II model. The electronic systems of this domestically produced car were upgraded as its relative in Europe. A 1.4 TSI, which can output 93 kW, was added to the new model.
New engines were available following the downsizing trend, a 1.2 with 77 kW (105 PS; 103 hp) and a new 1.6 Common Rail TDI with 66 kW (90 PS; 89 hp) or 77 kW (105 PS; 103 hp).[11] They replaced the 1.6 and 1.9 TDI from the previous model. The 1.2, 77 kW (105 PS; 103 hp) and 1.6 TDI 77 kW (105 PS; 103 hp) were also available as BlueMotion, Volkswagen's low fuel consumption vehicle program.
In 2012, the 125 kW (170 PS; 168 hp) engine was replaced with the 130 kW (177 PS; 174 hp).
Engines [edit]
The Touran is available with petrol, diesel and compressed natural gas (CNG) engines.
| Model | Years | Engine and code | Displ. | Power | Torque |
| 1.2 TSI | 2010–2015 | I4 8V | CBZB | 1,197 cc | 77 kW (105 PS; 103 hp) @ 5,000 rpm | 175 N⋅m (129 lb⋅ft) @ 1,550-4,100 rpm |
| 1.4 TSI | 2006–2010 | I4 16V | BMY/CAVC | 1,390 cc | 103 kW (140 PS; 138 hp) @ 5,600 rpm | 220 N⋅m (162 lb⋅ft) @ 1,250–4,000 rpm |
| 1.4 TSI | 2007–2015 | I4 16V | BLG/CAVB | 1,390 cc | 125 kW (170 PS; 168 hp) @ 6,000 rpm | 240 N⋅m (177 lb⋅ft) @ 1,500 rpm–4,500 rpm |
| 1.4 TSI EcoFuel | 2009–2015 | I4 16V | CDGA | 1390 cc | 110 kW (150 PS; 148 hp) @ 5,500 rpm | 220 N⋅m (162 lb⋅ft) @ 1,500–4,500 rpm |
| 1.6 | 2003–2010 | I4 8V | BGU/BSE/BSF | 1,595 cc | 75 kW (102 PS; 101 hp) @ 5,600 rpm | 148 N⋅m (109 lb⋅ft) @ 3,800 rpm |
| 1.6 FSI | 2003–2006 | I4 16V | BAG/BLF/BLP | 1,598 cc | 85 kW (116 PS; 114 hp) @ 6,000 rpm | 155 N⋅m (114 lb⋅ft) @ 4,000 rpm |
| 2.0 FSI | 2003–2006 | I4 16V | AXW/BLR/BLX/BVY | 1,984 cc | 110 kW (150 PS; 148 hp) @ 6,000 rpm | 200 N⋅m (148 lb⋅ft) @ 3500 rpm |
| 2.0 EcoFuel | 2006–2009 | I4 8V | BSX | 1,984 cc | 80 kW (109 PS; 107 hp) @ 5,400 rpm | 160 N⋅m (118 lb⋅ft) @ 3,500 rpm |
| 1.6 TDI | 2010–2015 | I4 16V | CAYB | 1,598 cc | 66 kW (90 PS; 89 hp) @ 4,200 rpm | 230 N⋅m (170 lb⋅ft) @ 1,500–2,500 rpm, |
| 1.6 TDI | 2010–2015 | I4 16V | CAYC | 1,598 cc | 77 kW (105 PS; 103 hp) @ 4,400 rpm | 250 N⋅m (184 lb⋅ft) @ 1,500–2,500 rpm, |
| 1.9 TDI | 2004–2010 | I4 8V | BRU/BXF/BXJ | 1,896 cc | 66 kW (90 PS; 89 hp) @ 4,000 rpm | 210 N⋅m (155 lb⋅ft) @ 1,800–2,500 rpm |
| 1.9 TDI | 2003–2004 | I4 8V | AVQ | 1,896 cc | 74 kW (101 PS; 99 hp) @ 4,000 rpm | 250 N⋅m (184 lb⋅ft) @ 1,900 rpm |
| 1.9 TDI | 2004–2010 | I4 8V | BJB/BKC/BXE/BLS | 1,896 cc | 77 kW (105 PS; 103 hp) @ 4,000 rpm | 250 N⋅m (184 lb⋅ft) @ 1,900 rpm |
| 2.0 TDI | 2003–2004 | I4 16V | AZV | 1,968 cc | 100 kW (136 PS; 134 hp) @ 4,000 rpm | 320 N⋅m (236 lb⋅ft) @ 1,750–2,500 rpm |
| 2.0 TDI | 2004–2010 | I4 16V | BKD | 1,968 cc | 103 kW (140 PS; 138 hp) @ 4,000 rpm | 320 N⋅m (236 lb⋅ft) @ 1,750–2,500 rpm |
| 2.0 TDI DPF | 2005–2010 | I4 8V | BMM | 1,968 cc | 103 kW (140 PS; 138 hp) @ 4,000 rpm | 320 N⋅m (236 lb⋅ft) @ 1,750–2,500 rpm |
| 2.0 TDI DPF | 2010–2015 | I4 16V | CBAB | 1,968 cc | 103 kW (140 PS; 138 hp) @ 4,200 rpm | 320 N⋅m (236 lb⋅ft) @ 1,750–2,500 rpm |
| 2.0 TDI DPF | 2005–2010 | I4 16V | BMN | 1,968 cc | 125 kW (170 PS; 168 hp) @ 4,200 rpm | 350 N⋅m (258 lb⋅ft) @ 1,750–2,500 rpm |
| 2.0 TDI DPF | 2012–2015 | I4 16V | CFJB | 1,968 cc | 130 kW (177 PS; 174 hp) @ 4,200 rpm | 380 N⋅m (280 lb⋅ft) @ 1,750–2,500 rpm |
The diesel models of the Touran offer better fuel economy. Given the proper conditions, it is possible to achieve over 60 mpg‑imp (4.7 L/100 km; 50 mpg‑US) in a diesel Touran.[12]
The car is delivered with a five- (1.6 only) and six speed manual transmissions, Tiptronic six speed automatic transmission (in 1.6, 1.6 FSI and 2.0 FSI (2003 to 2006 only)) or the DSG twin clutch automatic transmission; the 1.4 TSI, the 1.6 FSI from 2003 to 2006, the 1.9 TDI from 2003 to 2008, and the 2.0 TDI uses the six speed version, and the 1.9 TDI since the middle of 2008 use the seven-speed dry clutch version.
As for the 2010 model, an updated version of the 2.0 TDI engine was launched with common rail technology. The engine was introduced in the Volkswagen Passat in the models from 2008.
Touran Hy Motion and Hybrid [edit]
Touran HY MOTION Hydrogen Study
The Touran Hy Motion is Volkswagen's Hydrogen Development concept. It has a nickel-metal hydride battery which produces 80 kW (107 hp), it does the 0–100 km/h (0-62 mph) sprint in 14 seconds and has a top speed of 140 km/h (87.0 mph).
In 2008, Shanghai-Volkswagen with Tongji University had released a Touran Hybrid, as part of the lead up to the 2008 Beijing Olympic Games.
A prototype of the Touran Hybrid was shown with a 20 kW (27 hp) electric motor in conjunction with a 110 kW (148 hp) petrol engine, the transmission will most likely be Volkswagen's Direct-Shift Gearbox (DSG).
Awards and safety [edit]
- The Touran won What Car?'s 2005 Compact Van of the Year award.
- The Touran scored a maximum five star EuroNCAP crash safety rating.
Second generation (Typ 5T; 2015) [edit]
Motor vehicle
| Second generation (5T) |
 |
| Overview |
| Production | 2015–present |
| Assembly | Germany: Wolfsburg
China: Anting (SAIC-VW) |
| Designer | Walter de Silva |
| Body and chassis |
| Platform | Volkswagen Group MQB |
| Related | Volkswagen Golf Mk7
Volkswagen Golf Sportsvan |
| Powertrain |
| Engine | Petrol engines:
1.0 L OPF I3 TSI
1.2 L CYVB I4 TSI
1.4 L CZDA I4 TSI
1.5 L OPF I4 TSI
1.8 L EA888 I4 TSI
Diesel engines:
1.6 L SCR BMT I4 TDI
2.0 L SCR I4 TDI
2.0 L SCR BMT I4 TDI |
| Transmission | 5&6 speed manual
7 speed DSG |
| Dimensions |
| Wheelbase | 2,791 mm (109.9 in) |
| Length | 4,527 mm (178.2 in)
4,537 mm (178.6 in)
(Chinese market; 2021-present) |
| Width | 1,829 mm (72.0 in)
1,834 mm (72.2 in)
(Chinese market; 2021-present) |
| Height | 1,628 mm (64.1 in)
1,659 mm (65.3 in)/1,682 mm (66.2 in)
(Chinese market; 2021-present) |
The second generation Touran was introduced at the 2015 Geneva Motor Show. It uses the Volkswagen Group MQB platform and offers increased cabin space, four new engines with 19% less fuel consumption, and an array of new advanced driver-assistance systems and infotainment options.[13] Autoradio with Apple CarPlay and Android Auto is included as an option.
Visually, the car resembles Golf Sportsvan with an elongated rear trunk.
The Touran currently serves as the successor to the Volkswagen Santana in Shanghai's taxi fleet since October 2018, as the Santana was phased out. Qiangsheng, one of the largest taxi firms in Shanghai, stated that the Touran offered greater passenger comfort over its predecessor. 100 new electric cabs were also added to the taxi fleet.[14] The Chinese market Touran L is available in 280TSI and 330TSI trims with the 1.4 litre TSI, known as the CSS in China, available on 280TSI models and the 1.8 litre TSI for 330TSI models. A 5 speed manual gearbox option is available on 280TSI models along with the 7 speed direct shift gearbox. 330TSI models come standard with the latter gearbox. The Touran L came standard in 5 seater configurations only when new. Pricing in 2016 ranged between 155,800 yuan and 230,800 yuan with 7 trim levels (23,850 to 35,330 USD - January 2021 exchange rate). Trim levels were known as: 280TSI Fashion (manual and DSG), 280TSI Comfort (manual and DSG), 280TSI Elegant (DSG only), 280TSI Deluxe and 330TSI Deluxe.[15] A 1.6 litre engine was only available for the 2018 model year under the Fashion trim level. Six-seater and seven-seater configurations were added to the range for the 2018 model year onwards.
As of January 2021, for the 2021 model year, only one model, the 280TSI was available. Trim levels are known as: Fashion (7-seater), Comfort (7-seater), Extension (6 and 7 seater) and Deluxe (6 and 7 seater). Pricing ranges between 151,800 yuan and 194,800 yuan (23,235 to 29,820 USD - January 2021 exchange rate).[16]
Awards [edit]
- In January 2021, the Touran 1.5 TSI 150 SE was named MPV of the Year by What Car? magazine.[17] What Car? awarded the Touran five stars out of five in its review of the car.[18]
Engine specifications [edit]
Petrol engines[19] | Model | Year(s) | Displacement | Fuel Type | Power | Torque | 0–100 km/h (0–62 mph) | CO2 Emissions |
| 1.0 TSI OPF | 01/2019–07/2019 | 999 cc (61.0 cu in) | Petrol | 115 PS (85 kW; 113 bhp) | 190 N⋅m (140 ft⋅lbf) | 11.3 s | 125 g/km |
| 1.2 TSI CYVB | 05/2015–08/2018 | 1,197 cc (73.0 cu in) | Petrol | 110 PS (81 kW; 108 bhp) | 175 N⋅m (129 ft⋅lbf) | 11.3 s | 128 g/km |
| 1.4 TSI CZDA/CSS (China) | 05/2015– | 1,395 cc (85.1 cu in) | Petrol | 150 PS (110 kW; 148 bhp) | 250 N⋅m (184 ft⋅lbf) | 8.9 s | 126 g/km |
| 1.5 TSI OPF | 11/2018– | 1,498 cc (91.4 cu in) | Petrol | 150 PS (110 kW; 148 bhp) | 250 N⋅m (184 ft⋅lbf) | 8.9 s | 125-128 g/km |
| 1.8 TSI | 02/2016–05/2018 | 1,798 cc (109.7 cu in) | Petrol | 180 PS (132 kW; 178 bhp) | 250 N⋅m (184 ft⋅lbf) | 8.3 s | 140 g/km |
Diesel engines[19] | Model | Year(s) | Displacement | Fuel Type | Power | Torque | 0–100 km/h (0–62 mph) | CO2 Emissions |
| 1.6 TDI (SCR) BMT | 05/2015–04/2016 | 1,598 cc (97.5 cu in) | Diesel | 110 PS (81 kW; 108 bhp) | 250 N⋅m (184 ft⋅lbf) | 11.9 s | 115-118 g/km |
| 1.6 TDI (SCR) BMT | 04/2016–08/2019 | 1,598 cc (97.5 cu in) | Diesel | 115 PS (85 kW; 113 bhp) | 250 N⋅m (184 ft⋅lbf) | 11.4 s | 117-121 g/km |
| 2.0 TDI (SCR) | 08/2019–10/2020 | 1,968 cc (120.1 cu in) | Diesel | 116 PS (85 kW; 114 bhp) | 300 N⋅m (221 ft⋅lbf) | 11.3 s | 119–121 g/km |
| 2.0 TDI (SCR) | 10/2020– | 1,968 cc (120.1 cu in) | Diesel | 122 PS (90 kW; 120 bhp) | 320 N⋅m (236 ft⋅lbf) | 10.8 s | 116–121 g/km |
| 2.0 TDI (SCR) BMT | 05/2015–08/2018 | 1,968 cc (120.1 cu in) | Diesel | 150 PS (110 kW; 148 bhp) | 340 N⋅m (251 ft⋅lbf) | 9.3 s | 118–121 g/km |
| 2.0 TDI (SCR) | 11/2018– | 1,968 cc (120.1 cu in) | Diesel | 150 PS (110 kW; 148 bhp) | 340 N⋅m (251 ft⋅lbf) | 9.3 s | 122–123 g/km |
| 2.0 TDI (SCR) BMT | 02/2016–08/2018 | 1,968 cc (120.1 cu in) | Diesel | 190 PS (140 kW; 187 bhp) | 400 N⋅m (295 ft⋅lbf) | 8.2 s | 122-125 g/km |
| 2.0 TDI (SCR) BMT | 01/2019–07/2019 | 1,968 cc (120.1 cu in) | Diesel | 190 PS (140 kW; 187 bhp) | 400 N⋅m (295 ft⋅lbf) | 8.2 s | (125) g/km |
Gallery [edit]
